Booking System

This document outlines the system design for a simple online hotel reservation platform, similar to Booking.com.

Requirements

Functional Requirements

• Hotel Management: Hoteliers must be able to manage their properties, including details and room information.
• Searching: Users must be able to search for hotels by city or name. Clicking a search result should navigate to the hotel’s detailed page.
• Booking: Users must be able to book one or more available rooms of a specific type at a hotel.

Non-functional Requirements

• Consistency: The system must prevent booking conflicts, such as the same room being booked twice for overlapping dates.
• Availability: The application will primarily serve two regions: Southeast Asia and the United States.

System Overview

The system can be broken down into three main components:

• The Hotel Management Service allows hoteliers to manage their property information.
• The Search Service enables users to find available hotels.
• The Booking Service handles the room reservation process.

The term service here refers to a logical system component, not necessarily a microservice.

The design of the storage layer is fundamental, as it influences the entire system’s architecture. Therefore, we will analyze the data storage for each service first.

Hotel Management Service

A relational database is a straightforward choice for managing hotel data.

NoSQL Consideration

However, a key access pattern is that users typically work with only one hotel at a time. This locality allows us to leverage a NoSQL store (such as a Document Store or Column-family Store) to improve performance and availability. We can partition the data by hotel_id, ensuring that a hotel and all its associated rooms reside on the same server.

Furthermore, NoSQL stores often provide a schemaless design, which is beneficial in the hospitality industry where properties can have a wide variety of attributes.

Search Service

Our search requirements include finding hotels by city or by name. However, our primary data store is partitioned by hotel_id, which is not efficient for these search queries.

Complete Search

A simple approach is to create duplicated datasets to serve these queries directly. We would create two new tables:

• HOTEL_BY_CITY is partitioned by city.
• HOTEL_BY_NAME is partitioned by name.

With this design, a search query can be directed to the exact data partition, significantly improving performance. However, this comes at the cost of increased storage, as each hotel record is now replicated three times. A major drawback is the poor user experience, as it requires users to type the exact hotel or city name.

Prefix Search

To support a better search-as-you-type experience, we need to handle prefix searches. Partitioning by the full name is insufficient for this. Instead, we can distribute data based on the leading characters of names or cities.

For instance, names starting with A-B go to server_0, C-D go to server_1, and so on.

This allows a prefix search to be routed to a single node. However, this approach is limited. For more advanced features like fuzzy search, spell correction, or relevance ranking, a dedicated Search Engine is a better solution.

Full-text Search

To provide a rich user experience with features like autocompletion and spell correction, we can employ a Search Engine.

For this project, we will use a Search Engine store to provide a rich experience. To keep the search index synchronized with the primary database, data will be asynchronously replicated from the Hotel Store.

Problems

While powerful, search engines are complex and can be costly to manage. A significant challenge with search engines is data sharding. There is no simple criterion to distribute full-text terms efficiently. This means a single search query often needs to be broadcast to multiple nodes, and the results must be aggregated. This scatter-gather pattern can be problematic, especially for pagination.

For example, to fetch a page of 30 results from 5 partitioned servers, each server might need to return its top 30 results. The application then has to sort through 150 records to produce the final page.

Booking Service

To handle bookings, we first need a table to store booking information.

A booking is valid only if the number of rooms being booked (booked) is less than or equal to the number of rooms available (available). The booking transaction follows these steps:

This sequence, however, introduces potential concurrency conflicts when multiple users try to book the same room type simultaneously.

To learn more, refer to this article on Concurrency Control.

• Unrepeatable Read: This occurs when two transactions read the same data, but one modifies it before the other completes. In our case, two users might both see that a room is available, but one user’s booking could reduce the available count to zero, causing the second user’s subsequent update to result in a negative available count.

• Phantom Read: This happens when new records are inserted into a table that match the WHERE clause of a query in another ongoing transaction. For example, two users could both verify availability and then proceed to create booking records. This could lead to the total number of booked rooms exceeding the original available count.

In traditional relational databases, the Serializable isolation level is typically required to prevent phantom reads. However, in this specific scenario, the Unrepeatable Read conflict occurs first; By resolving it, we consequently prevent the phantom read from happening. Therefore, the Repeatable Read (or Snapshot Isolation) level is sufficient.

This brings us to our NoSQL implementation. Since we partition ROOM records by hotel_id, all transactions for a single hotel (even if they involve multiple room types) are processed on the same partition. Many NoSQL solutions can efficiently enforce transaction isolation at the single-partition level, allowing us to prevent these concurrency issues effectively.

Implementation

This section details how to deploy the designed booking system within the AWS environment.

Multi-region Setup

The system is required to serve users primarily from two regions: Southeast Asia (ap-southeast-1) and the United States (us-east-1). While deploying to a single region reduces costs significantly, it would result in high latency and a degraded experience for users far from that region. A single-region deployment also introduces a single point of failure; an outage in the primary region would bring down the entire system.

Therefore, we will deploy the system independently in both regions. This approach increases cost and complexity, primarily due to the need for an effective data synchronization mechanism between the regions. This consideration will be central to the design of the following components.

Database Layer

Our design utilizes two distinct data stores:

• A Hotel Store for managing hotel properties and processing bookings.
• A Search Store for enabling full-text searches on hotel names and cities.

Hotel Store

The Hotel Store must excel at two primary functions: partitioning data and handling concurrent write conflicts. Several databases, including MongoDB, Cassandra, and Amazon DynamoDB, are capable of meeting these requirements.

While open-source solutions offer flexibility and easier migration to other providers, DynamoDB, a proprietary, serverless NoSQL database from AWS, providing significant advantages within the AWS ecosystem. It reduces operational overhead, simplifies management, and offers seamless integration with other AWS services. Given our focus on an AWS implementation, we will use DynamoDB.

DynamoDB supports a multi-region setup natively through its Global Tables feature. This feature employs an active-active replication model, where writes can occur in any region. Conflicts are resolved using a last writer wins strategy.

Cross-region Conflicts

While DynamoDB supports serializable isolation for transactions within a single region, this guarantee does not extend to Global Tables due to their asynchronous replication. A transaction can complete successfully in one region but be subsequently overwritten by a newer change from another region (due to last writer wins), potentially leading to data inconsistencies.

For more details, refer to the AWS documentation on transactions in DynamoDB.

To prevent this, we need to enforce a single-writer principle, ensuring that all modifications to a specific record occur in only one region. There are two primary ways to achieve this:

• Designate a Primary Region: Route all write operations to a single primary region (e.g., us-east-1), while the other region (ap-southeast-1) serves only read operations. This approach turns the primary region into a potential bottleneck and increases latency for users far from it.

• Regional Data Ownership: Assign ownership of data to a specific region. For example, us-east-1 handles writes for hotels in western countries, while ap-southeast-1 handles writes for hotels in eastern countries.

To implement the second, preferred approach, we add a managed_in field to our schema to control routing for booking operations. The final data model for the Hotel Store looks like this:

Search Store

We will deploy an Amazon OpenSearch cluster to serve as our full-text search store.

Data must be replicated from the Hotel Store to this one. DynamoDB facilitates this with Amazon OpenSearch Ingestion. This service creates a pipeline that pulls new records from DynamoDB Streams and automatically flushes them to an OpenSearch cluster.

Since OpenSearch does not natively support a multi-region active-active setup, we will maintain two separate search clusters, one in each region. Each cluster will be replicated from its respective regional DynamoDB table.

Web Service Layer

We will build two separate, stateless services, Hotel Service and the Search Service, to manage the data stores, allowing them to scale independently. These can be quickly deployed using the following AWS services:

• Amazon Elastic Container Service (ECS): To run the services as containerized applications.
• Application Load Balancer (ALB): To distribute incoming traffic across the service instances.
• Amazon Route 53: To route user traffic to the region with the lowest latency using latency-based routing.

This setup will be duplicated in two VPCs, one in each region.

Internal Accessing

To ensure secure and efficient communication between our services and the AWS-managed data stores, we will use AWS PrivateLink.

• DynamoDB: We can access DynamoDB privately and efficiently using VPC Gateway Endpoints, which are fast and do not incur data processing charges.
• OpenSearch: Since the OpenSearch cluster is deployed within our VPC, the service instances can access it directly. However, for the data ingestion pipeline to communicate with OpenSearch, we need to set up a VPC Interface Endpoint.

Routing Bookings

To prevent the cross-region write conflicts discussed earlier, booking requests for a hotel must be processed in its designated region. When a user sends a booking request to the closest (lowest-latency) region, the service must check if it is the correct region to handle the write. If not, there are two ways to proceed:

1. Server-Side Cross-Region Request: The receiving server performs a cross-region request on behalf of the user to the correct region’s service. This can be implemented using VPC Peering and an Interface Endpoint (as Gateway Endpoints do not support communication outside a VPC). This approach minimizes user-perceived latency but incurs additional costs for cross-region data transfer and the Interface Endpoint.

2. Client-Side Redirect: The server responds with a redirect, instructing the client to send a new request to the target region. This increases latency because the second request must travel over the public internet, but it avoids internal data transfer costs.

To prioritize a seamless user experience, we will use the first approach (server-side cross-region request).
